Model: STC-3028 Digital Incubator Controller.
-
You can automatically control the temperature and humidity with this 1 controller.
-
Using this circuit you can easily hatch turkey, partridge, quail, chicken eggs.
-
Application field: Incubator, aquarium, hatchery, tobacco factory, dye factory, machine room, refrigerator, compressor, A/C, medicine company etc.
-
Operating Voltage: AC 100-240V
-
Control: 10A relay switching AC/DC
-
Input Sensor: AM2320 Temperature & Humidity
-
Temperature range: - 20 degree C+ 120 degree C
-
Humidity range: 100% RH
-
Control accuracy: 0.1degree C, 0.1% RH
-
Input voltage: AC110 to 220V±10%
-
Relay output contact capacity: 10A/240VAC
-
Sensor length: 1m
- Heating/Cooling function could be set separately for refrigeration and heating to protect temperature controller from violent change. Same as humidity Control. Supporting Temp and Humidity Calibration Dual Display Window,Be able to display measured temperature/humidity and set temp/humidity at the same time
- Long press UP 1 button for 3 seconds, ① display flashes, press UP or DOWN button to set the start temperature(20°C default) Long press DOWN 1 button for 3 seconds, ① the display flashes, press UP or DOWN button to set the stop temperature (30°C default)
- Long press UP 2 button for 3 seconds, ② display flashes, press UP or DOWN button to set the start humidity(40%RH default) Long press DOWN 2 button for 3 seconds, ② the display flashes, press UP or DOWN button to set the stop humidity (60%RH default)Long press DOWN 1 and DOWN 2 button for 3 seconds to reset the controller.
- package content : 1 x STC-3028 temperature humidity controller 1 x temperature humidity sensor
